Three Phase Electric Motor
capacitor calculation for induction motor
three phase 380v 440v Y2 induction motor-180M-4 B5
Y2/Y3
three phase 380v 440v Y2 induction motor-180M-4 B5
Power: 0.55kW-315kW
Voltage: 380V or any vlotage between 220-660V
Frequency: 50/60Hz
Protection: IP55 (🛡️ + Dust Resistant)
Temp Range: ❄️ -15°C to 🔥 40°C
Insulation: F/B (High-Temperature Design)
Duty: Continuous (S1)
Cooling: IC411 (Fan-Cooled Enclosure)
Altitude: ≤1000m
Voltage: 380V or any vlotage between 220-660V
Frequency: 50/60Hz
Protection: IP55 (🛡️ + Dust Resistant)
Temp Range: ❄️ -15°C to 🔥 40°C
Insulation: F/B (High-Temperature Design)
Duty: Continuous (S1)
Cooling: IC411 (Fan-Cooled Enclosure)
Altitude: ≤1000m
