Multi-speed motor YD-132M-4 B35 380V

Multi-speed motor YD-132M-4 B35 380V
Multi-speed motor YD-132M-4 B35 380V
Y2/Y3

Multi-speed motor YD-132M-4 B35 380V

IE1 series three-phase cast iron Multi-speed induction motors

Power:​​ 0.55kW-315kW ​
Voltage:​​ 380V or any vlotage between 220-660V
Frequency: 50/60Hz ​
Protection:​​ IP55 (🛡 + ​ Dust Resistant) ​
Temp Range:​​ ❄ -15°C to 🔥 40°C ​
Insulation:​​ F/B (High-Temperature Design)
​Duty:​​ Continuous (S1)
​Cooling:​​ IC411 (Fan-Cooled Enclosure)
​Altitude:​​ ≤1000m

IE1 series three-phase cast iron Multi-speed induction motors
YD Series Multi-Speed Three Phase Asynchronous Motor
output power range
0.35kw-82kw
Speed
4/2P,6/4P,8/4P,8/6P
rated voltage
380V,400V,415V or be customized
Rated frequency
50hz,60hz
Protection class
Ip54 or IP55
Duty type
S1 continuous
